CCTV Security Cameras Product Store Choice Collections provide security surveillance, spy camera,remote cctv Wonderful Promotion Hot SDI Splitter 1x4 Multimedia Split SDI Extender Adapter Support 1080P 3G/HD/SD-SDI For Projector Monitor Camera CCTV DISP0104. Price at this time US $79.98/piece. Check price now to get discount! Dont waste your time. Buy Now only in China Shenzhen RuiHuiXing Store Trusted Seller Store!
4 Port SDI Splitter
(3G / HD/ SD-SDI TO Repeater)
Model No: SDISP0104
FEATURES
*One Signal distribute to four SDI signal out.
*SupportSD-SDI, HD-SDI and 3G-SDI Video Format.
*SDI Supports1080P/1080I/720P/576I/ 480I Video Resolution.
*Support SDI transmission Speed: SD-SDI:270MbPs.HD-SDI:1.485GbPs and 3G-SDI: 2.97GbPs.
*Supported Max Cable Length(SYV-75-5):SD supports up to 400m,HD supports up to 200m, 3G supports up to 80_100m(Note: The cable length will depend on the cable spec)
*Support deep color 8bit, 10bit, 12bit
*Support up to 3G-SDI
*Audio and Video Output Simultaneously
*Support Clock Recovery
*No Any Drive Need, Support Hot-Plug, Plug and Play
*Wide voltage input, It can support DC 5V~ 12V input
PACKAGE CONTENTS:
1Main unit 1PCS
25VPower Adaptor1PCS
3one pc of Manual1PCS
Physical Connection Showing Picture
Picture 1.0Front Panel View
OUT:SDI output led status light
POWER:Power Led Status Light
Picture 1.1Back Panel View
DC 5V~12V:5V~12V DC-DC Power Adaptor Interface.
IN:SDI inputinterface
OUT1-OUT4:SDI output interface
Operating and Connecting
1. To use one coaxial cable to connect the SDI source with the SDI Input port of the splitter.
2. To use the coaxial cable to connect the SDI display with the SDI output port of the splitter.
3. To connect the power adaptor with the SDISplitter.
SPECIFICATIONS:SDISP0104
Support SDI Format........................................................SD-SDI,HD-SDI and 3G-SDI
SDIresolution..................................................................1080P/1080I/720P/576I/ 480I
Support video color format ......................................................8bit/deep color 10bit,12bit
Audio Signal..........................................................................................SDI Built-in
SDIbaudrate........................................................270Mbps1.485Gbps and 2.97Gbps
Coaxial cable Characteristic impedance..................................................................75Ω
Max working current..............................................................................300mA/DC 5V
Power adapter format.............Input: AC (50HZ, 60HZ) 100V-240V; Output: DC5V~12V/2A
Operating Temperature range................................................................... -10 to +55
Storage Temperature range..................................................................... -20 to +60
Operating Humidity range................................................10 to 90%RH (No Condensation)
Storage Humidity range....................................................5 to 95%RH (No Condensation)
Dimension (L x W x H) ......................................... ............................178X66X28(mm)
Weight............................................................................................. ...............418g
