CCTV Security Cameras Product Store Choice Collections provide remote cctv,camera system Big Stock Special HQCAM Mini AHD Camera 5.0MP Camera Indoor Security CCTV Camera DIP switch 4 IN 1 AHD5MP/4MP,TVI5MP/4MP,CVI4MP,CVBS. Price at this time US $46.20/piece. Check price now to get discount! Dont waste your time. Buy Now only in HQCAM Official Store Trusted Seller Store!
Note:support UTC,Please tell me that the UTC function is required, and the default package does not support UTC.
Features and specifications:
Specifications:
• Horizontal resolution: Super 5.0 MP
• Effective pixels (H/V): 2560x2048
• Operation temperature: -20 to 60℃ (Relative humidity: 95% maximum)
• Main PCB:FH8538M+IMX326 for 5MP (25 fps)
• 5MP is AHD, CVI, TVI, CVBS 4-in-1
Reminders:
1) You can use the DIP switch to change the mode.
2) This item is the AHD camera. AHD signal is not the analog signal. AHD cameras must be paired with the AHD signal DVR.
2) AHD5MP is not the same as IP 5MP, AHD is the analog signal, but shows digital images.
3) AHD5MP support the AHD 5MP DVR
4) AHD5MP can not support AHDNH,AHDH DVR,AHD5MP DVR.
5) AHD cameras cannot work with TVs or other monitors. If you use the AHD tester, please make sure your tester has the right signal.
6) If you do not know which is AHD 5MP, please check the Digital option in your DVR menu to view 5MP.
7) This camera has no IP features
Model No. | |
VIDEO | |
Main PCB | FH8538+IMX326 For 5MP AHD This sensors is the SUPER sensor in AHD5MP AHD5MP/4MP,TVI5MP/4MP,CVI4MP,CVBS |
Image Sensor | IMX326 |
DSP | FH8538 |
Horizontal Resolution | 5.0Megapixal |
Effective Pixels | 2560x2048(H/V) |
TV System | AHD Single |
Sync System | Wired |
Usable Illumination | color 0LuxaF1.2,black/white 0.1LuxaF1.2 |
S/N Ratio | ≥55dB(AGC Off) |
Video Output | 1ch BNC high resolution output |
LENS | |
Focal Length | 3.7mm (2.8mm 6mmoptional) |
Lens Type | Fixed |
OPERATIONAL | |
DAY & NIGHT | Auto |
ICR | YES |
2DNR/3DNR | YES |
Frame | 2560x2048@25fps/NTSC 30fps |
Singal interface | |
White Balance | Auto |
Gama Correction | >R0.45 |
Electronic Shutter Speed | 4/25s~1/45,000s |
BLC | Auto |
Gain Control | Auto |
LED | NO |
IR Status | NO |
IR Power On | NO |
IR Distance | NO |
Power Consumption | <3W |
Power Supply | DC12V ±10% |
MECHANICAL | |
Weatherproof Housing | NO |
Color/Material | NO |
Cut-proof Bracket | NO |
Operation Temperature | under-10℃~ +50℃RH95% Max |
Storage Temperature | under20℃~ +60℃RH95% Max |
Weight | |
Dimensions (W×H×D) | |
PACKAGE | |
Package List:
1x 4 in 1 camera
1x manual
1x screw bag
Note:*Please select the PAL or NTSC Correctly according to your country*The following section arrow can choose to place an order, please send to the seller confirm.
